The S6-EH1P6K-L-PLUS from Solis is a cutting-edge single-phase hybrid inverter designed to elevate residential solar energy systems.
| Model Number | S6-EH1P6K-L-PLUS |
|---|---|
| Dimensions (W × H × D) | 335 × 560 × 253 mm |
| Weight | 23.5 kg |
| Rated Output Power | 6,000 W |
| Max. DC Input Power | 9,600 W |
| Max. DC Voltage | 500 V |
| MPPT Voltage Range | 90–435 V |
| Number of MPPTs / Strings per MPPT | 2 / 1 |
| Max. Input Current per MPPT | 16 A |
| Nominal AC Voltage | 230 V |
| AC Frequency Range | 45–65 Hz |
| Battery Voltage Range | 40–60 V |
| Max. Charge/Discharge Current | 135 A |
| Protection Rating | IP65 |
The Solis S6-EH1P6K-L-PLUS is a powerful single-phase hybrid inverter designed to meet the evolving energy needs of modern homes. With a 6 kW output capacity, it effortlessly integrates solar power generation and battery storage, enabling homeowners to maximize self-consumption and maintain energy independence. Its dual MPPT design supports high-current PV modules, while intelligent battery management ensures safe and efficient operation with a wide range of low-voltage lithium-ion batteries. The inverter features advanced energy scheduling with six-stage time-of-use charge and discharge settings, allowing users to optimize energy usage based on tariff structures. In the event of a power outage, its built-in UPS functionality and generator interface provide reliable backup power with rapid switching. For larger installations, the S6-EH1P6K-L-PLUS supports parallel operation of up to six units, enabling scalable systems up to 48 kW in single or three-phase configurations. With integrated AFCI protection and remote monitoring via SolisCloud, this inverter offers a smart, secure, and future-ready solution for residential solar energy systems.
